Description
The 4624N is an AC Axial Fan with external rotor shaded pole motor, AC low-voltage version. Metal fan housing and impeller. Electrical connection via 2 flat pins 3 x 0.5mm. Air intake over struts. Rotational direction CW looking at rotor.
Protected Against Overloading (Impedance Protected)
Designed for Maintenance-free Long-term Operation
Any Mounting Position
3100RPM Nominal Speed
Sleeve Bearing
Supply Voltage: 24V
Current Type: AC
Fan Frame Size: 119mm
External Depth: 38mm
Noise Rating: 50dBA
Flow Rate – Imperial: 105.9cu.ft/min
Flow Rate – Metric: 2.97m³/min
Bearing Type: Sleeve
Power Connection Type: Terminals
Current Rating: –
Product Range: 4000N Series
Condition:New
Manufacturer Part Number:4624N
Brand:EBM Papst
Weight:1.2lbs (544.3g)
